Brazed plate heat exchangers deliver compact, high-performance heat transfer with corrugated stainless steel plates permanently brazed together. They offer exceptional efficiency, minimal footprint, and resistance to high pressures and temperatures in demanding HVAC, refrigeration, and process applications.
- Multiple Designs: Standard, all-stainless, asymmetric channels, high-pressure CO2 models.
- Available Capacities: From small compact units to large industrial models handling high thermal loads.
- High Quality: 316L stainless steel plates, copper or nickel brazing for durability and compatibility.
- Efficiency: High turbulence from corrugated plates maximizes heat transfer and reduces fouling.
- Custom Options Various plate sizes, port configurations, and coatings for specific needs.
- Materials All-stainless for aggressive fluids; high-pressure designs for CO2 and beyond.
Industrial:
High Efficiency & Compact
- High Pressure & Temperature
- Minimal Footprint
- Custom Configurations
HVAC & Refrigeration:
Chillers, Heat Pumps & DX
- High NTU Efficiency
- Low Refrigerant Charge
- Compact & Lightweight
Standard:
Copper Brazed
- Cost-Effective
- High Thermal Performance
- Wide Application Range
All-Stainless:
Nickel Brazed
- Corrosion Resistant
- Aggressive Fluids
- High Purity Applications
Brazed Plate Exchangers
Applications
The following is a list of typical processes that require brazed plate heat exchangers: HVAC, heat pumps, chillers, evaporators, condensers, oil cooling, hydraulic cooling, data center cooling, district heating, refrigeration, process heating/cooling, and heat recovery.
Sizes & Materials
Brazed plate units feature 316L stainless steel plates, copper or nickel brazing, and designs from compact 3×8" to large industrial frames. They handle pressures up to 2030 psi and temperatures from -196°C to 225°C. Asymmetric channels, high-performance plate patterns, and optional coatings optimize efficiency and reduce fouling.
Available in standard, all-stainless, and high-pressure models with multiple connection types and full compliance to ASME, PED, and other standards. Compact design and high turbulence make them ideal for space-limited and high-efficiency applications.
Standard Brazed Plate
Copper-brazed models offer excellent thermal performance and cost-effectiveness for most water, oil, and refrigerant applications with good compatibility and high efficiency.
All-Stainless Brazed Plate
Nickel-brazed or diffusion-bonded all-stainless designs provide superior corrosion resistance for aggressive media, high-purity processes, and applications requiring no copper.
Some Brazed Plate Applications
- Chillers
- Oil Cooling
- Glycol Cooling
- Heat Recovery
- Hydraulic Cooling
- Refrigerant Condensers
- Refrigerant Evaporators
- Process Cooling
